● . Compatible with PCIe I/II/III x 4 interface
● . Compliant with NVMe 1.2
● . Support APST、 ASPM、L1.2 Saving Modes
● . Excellent data transfer speed
● . SMART disk Health Monitoring
● . Support Trim command
产品介绍
规格
| Form Factor | PCIe SSD |
| NAND Flash | MLC |
| Capacity | MLC: 240GB~002TB |
| Transfer Mode | PCIe Gen I/II/III |
| Performance | Read up to 2800MB/s; Write up to 1550MB/s |
| Operating Temperature |
Standard: 0℃~+65℃ Storage: -40°C ~ 85°C |
| Shock | 1500G@0.5ms |
| Vibration | 20G@80Hz~2000Hz |
| Dimension LxWxH (mm) | 167.65mm (L) x 68.90mm (W) x 17.14mm (H) (HHHL) |
| Model Number Decoder | AIC-HLUD |
订购信息
| WAI322-001TC | PCIe gen3*2 | Bics3 | 1TB | -40°C to +85°C | ||
| WAI322-512GC | PCIe gen3*2 | Bics3 | 512GB | -40°C to +85°C | ||
| WAI322-256GC | PCIe gen3*2 | Bics3 | 256GB | -40°C to +85°C | ||
| WAI342-128GC | PCIe gen3*2 | Bics3 | 128GB | -40°C to +85°C | ||
| WAI322-001TD | PCIe gen3*2 | Bics3 | 1TB | 0°C to +70°C | ||
| WAI322-512GD | PCIe gen3*2 | Bics3 | 512GB | 0°C to +70°C | ||
| WAI322-256GD | PCIe gen3*4 | Bics3 | 256GB | 0°C to +70°C | ||
| WAI322-128GD | PCIe gen3*2 | Bics3 | 128GB | 0°C to +70°C |
Data Sheet
| WPE341-XXXXX | 2017-06-09 18:23:10 |  |
|---|
